Butterfly valve wafer Lever Ductile iron/Aluminium bronze/NBR PN10/16-ANSI150-JIS5K/10K
Butterfly valve wafer Lever Ductile iron/Aluminium bronze/NBR PN10/16-ANSI150-JIS5K/10K
| Model: |
Wafer Series M52 |
Material body: |
Ductile iron JS1030 GGG40 |
| Connection: |
PN10/16/ANSI150#/JIS5-10K |
Material disc: |
St.St. ASTM A351 CF8M |
| Pressure: |
16 bar, check tech data PDF |
Material seat: |
NBR |
| Temperature: |
-0°C +80°C |
Operation: |
Lever |
| Test standard: |
EN 12266-1 |
Brand: |
MerxTrade Premium |
Cartridge seat design
|
| Approvals : WRAS, DVGW, CE/PED 97/23/EC category III module H (inquire at Merxtrade BV) |
| Marine body casting Type Approvals for: DNV/GL & Lloyd's register of shipping |
Application: Horticulture, agriculture, greenhouse construction, boiler houses, shipbuilding, industry, heating, pump systems, engine rooms, marine,
The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.
| SKU: | MXT-M52L030000 |
| Body material |
Ductile iron GGG40. |
| Disc / Ball / Wedge |
Aluminium-Bronze |
| Seat |
NBR |
